HGLRC Forward 2408 1700KV 6S/ 2500KV 4S Brushless Motor for RC Drone FPV Racing

$29.89

SKU: RC1450934 Category:

HGLRC Forward 2408 1700KV 6S/ 2500KV 4S Brushless Motor for RC Drone FPV Racing
Specification:
Brand name: HGLRC
Item name: Forward 2408 Brushless Motor
KV: 1700KV/ 2500KV (option)
Rated Voltage(V): 1700KV 24(6S)/ 2500KV 16(4S)
Stator Diameter(mm): 24
Overall Dimension(mm): Φ28.7 x 18.6
Stator Height(mm): 8
Shaft Diameter(mm): Φ5
No.of Stator Slots: 12
Lead Wire Size: 18AWG x 150mm
No.of Rotor Poles: 14
ESC: 40-50A
Shaft Style: Stainless steel SUS420
Magnet: Sintered NdFeB N45SH
Magnet Wire: Class H 180℃ Enameled Wire
Rotor Runout(mm): ≤0.1
Dynamic balance(mg): ≤10
Weight(Without wire): about 37g
Package Content:
1x Forward 2408 1700KV/2500KV Brushless Motor

Order Note:Order this product,please provid the option as follows to order notes on checkout page.
KV 2500KV/KV 1700KV/
