This sound unit is developed for advanced users. It is ideal sound and light control system for 1:87 micro model RC conversion. It could be used to 1/87, 1/72, 1/48, 1/35 and 1/32 RC model. This sound unit is 100% compatible TBS Micro sound unit. This module does not have preload sound, you have to work with a programming cable and software to upload sound and make settings before use it.
Internal 1W amplifier at 8 Ohm speakers
Receiver signals are used for speed information
Fully assembled in SMD technology (no heavy, vibration sensitive components)
Very little dimensions and weight
Dimension: 11x16x3,2mm(Version A) 11 x 23,5 x 3,2mm(Version B)
Voltage: 3.7V to 5V (supplied by the receiver) Note the maximum supply voltage of 5V!
Current: app. 10mA without sound, app. 250mA at max. volume
Speaker: 8-32 Ohm
Output power: 1W at 8-Ohm at 5V; 0,6W at 8-Ohm at 3V
Proportional inputs: Positive Impuls 1ms bis 2,0ms
Sound quality: up to 22,05 kHz
Manual, software and sound are available, please click here.Optional (A): Without JST plug
Optional (B): With JST plugPackage Content:
1 x Micro Sound Unit
Order Note:Order this product,please provid the option as follows to order notes on checkout page.
