Upgrade DYS 30.5×30.5mm F4 Pro V2 Flight Controller AIO OSD & 5V 9V 3.3V BEC & Current Sensor

SKU: RC1136875

$48.90

Out of stock

Ship From:China
Dispatch:Ship between 2 bussiness days
Payment Methods:Paypal & Credit Cards and more >Buyer Protection:
Full Refund ,If you do not receive your order
Full or Partial Refund , If the item is not as described more >payment

Share:
Size

Recommended for You

Description

Upgrade DYS 30.5×30.5mm Omnibus F4 Pro V2 Flight Controller AIO OSD & BEC & Current Sensor

Specification:
Brand Name: DYS
Model: F4 Pro V2
Item Name: F4 Pro V2 FC AIO OSD BEC and Current Sensor
MCU: STM32F405
Gyro: MPU6000
Input Voltage: Support 3-6S Lipo
BEC Output: 5V@ 3A
: 3.3V @ 0.3A
– Also have 9V @ 1.2A
Size: 38 (L)X386(W) mm
Hole Distance: 30.5×30.5mm
Net Weight: 10.5g (not including cable)
Features:– The refresh rate of PID and gyro up to 8K
– PCB 3OZ copper enhance current stability and cooling fast
– Exposed pad for easy soldering
– Support BF setting software to flash and debug OSD
– Integrated current sensor to monitor the real-time power consumption
– Use remote control to view flight control parameter through OSD
– Support SAMRT AUDIO, adjust the VTX by OSD
– Comes with heat resistance damping ball to upgrade the stability and operation
– 3-6s lipo input, integrated PDB, max withstand current 160A
New upgradable fucntion:
1. It can use S5,S6 motor control signal pad after updating firmware
2. Has the reverse high voltage protection circuit to the PCB board.
3. Added 9V/1.2A power output & 5V/3A one-way output
4. With 8pin socket to compatible with 4 in 1 ESC
5. Added Protection Circuit for USB Port
7. Added 8 Pin Port for 4 In 1 ESC
8. Compatible with DYS 20A / 30A 4 In 1 ESC.
Package Content:
1x DYS F4 Pro V2 Flight Controll Board
3x Cable
1x XT60 Connector
1x Manual
1x bag of Screws
