HGLRC Rekon 5 HD 222mm Wheelbase F722 Mini 5 Inch Long Range FPV Racing Drone with 28A ESC M80 GPS DJI O3 Air Unit Digital System
Summary/span>
Rekon 5 is based on the original Dave_C FPV mini remote design, this 5 inch drone is a mini longrange concept frame, suitable for carrying more loads.Like its smaller 4-inch drone, this 5 inch drone can achieve a flight time of about 25 minutes.
At the same time, it is very quiet, efficient, and relatively low cost compared to the 7 inches usually used for longrange flight.Compared with the 4 inch drone, the main advantage of the 5 inch drone is that it is compatible with Gopro and 18650 lithium batteries without affecting the flight performance and noise level. In addition, the cruising speed is increased, and the ability to do Freestyle is significantly improved.
The drone can also be used with a wide range of batteries: 4S 850-1800mAh, 6S 550-1300mAh, and if you need greater flight time, you can use a 18650 3000mah battery.
Frame design
The Rekon 5 features an innovative rack design featuring integrated front and rear arms locked by 7050 chainring screws.
The screws are used to create a strong and rigid part in the center part of the frame, which locks the arms and decouples the force from the rest of the frame.
This enables the use of very light M2 screws and thin carbon fiber plates in the rest of rack, reducing overall weight for maximum efficiency, and most importantly the chainring screws can handle higher torques and not usual happens with M2 or M3 screws break or detach easily.
The design of the front TPU camera seat and the naked bracket for gopro has also received a lot of attention. Since the arm extends backwards and the drone head is partially exposed, the dead cat frame is prone to collisions at the drone head, but the Rekon 5 will fly very quickly and flexible
Features:
-Using 10mm 7050 crankset screw structure light frame, can be used for 20×20 Stack
-Integrated TPU camera mount for Gopro
-Foldable 90-degree black sheep T-shaped antenna, to solve the problem of dead U-turn
-Optional arm protection bar for improved vibration and enhanced crash performance
-Optimize the drone fixing method and add two M2 screws to ensure that the arm is fixed more firmly
-Independent GPS M80 Print
-Independent search drone buzzer Print
Specification/span>
Model: Rekon5 HD ( DJI O3 Version)
Frame: Rekon5 LR
Wheelbase: 222mm
Arm thickness: 4mm
FC: Zeus F722 mini flight controller
Gyroscope: BMI270
ESC: ZEUS 28A 4in1 ESC
VTX: DJI O3 Air Unit VTX
Motor: Rekon 2004 1800KV 6S
Propeller: GEMFAN 5125 3-blade propeller
GPS: M80 GPS
Buzzer: Soter buzzer
Weight: 245g (weight without receiver)
Recommended battery: ( NOT Included)
18650_2000mah/18650_3500mah
Shipping list:
1x Rekon5 LR Long Range
2x 3mm arm protection bars
1x Black TPU mount for gopro naked
2x GF5125 propellers (set)
2x Rekon 15*200mm Battery Straps
1x Screw Kit
